MANET Radio
Created with Pixso. Dynamic Networking MANET Radio Seamless Communication For Rapidly Moving Fleets
Detail Information
Place of Origin:
China
Certification:
CE
Interface:
Serial Port, Ethernet Port, Power Interface, RF Interface
Net Device Dimensions:
≤430*353*44mm
Net Device Weight:
≤6.5kg
Bandwidth:
5/10/20/40MHz (Adjustable)
Frequency Range:
UHF、L、S, Customizable
Packaging Details:
box
Highlight:

Dynamic Networking MANET Radio

,

MANET Radio Seamless Communication

,

Rapidly Moving Fleets MANET Radio

Product Description

Product Introduction

Engineered for high-speed mobility, the radio utilizes independently developed physical and routing protocols to maintain high-speed transmission in challenging non-line-of-sight conditions. Ideal for vehicle formations and mobile command scenarios, this rack-mountable unit is designed for medium to large vehicles. It ensures continuous private network connectivity on the move, supported by a customizable chassis to fit specific vehicle requirements.



Product Features:
- Multiple Encryption: Supports multiple software encryption methods such as AES, ZUC, and SNOW3G.
- Intelligent Routing: Equipped with an intelligent dynamic routing algorithm, all nodes transmit signals on the optimal path without manual intervention.
- Intelligent Frequency Selection: Supports intelligent frequency selection, with adjustable bandwidths of 5/10/20 MHz.
- Public Network Communication: Customizable 4G/5G public network functions, enabling cross-regional remote transmission via public network signals.
- Dynamic Networking: Features dynamic networking capabilities, ensuring normal data transmission even when vehicles are moving at high speeds of up to 200 km/h, without affecting the stability of data transmission.



Specifications


Encryption

Support software encryption

Power Supply

Battery-powered, DC external power supply

Modulation

BPSK/QPSK/16QAM/64QAM,dynamic self-adapting

Networking capability

32 nodes, support customization

MIMO Mode

2T2R

Voice function

PTT voice communication system

Network port

100-megabit data network port

Other functions

Time Division multiplexing, frequency division multiplexing, beam forming, MIMO
